Flange Motors

Name: Flange Motors
Brand: Powergrow Electricals LLP
Price: 5000.0 INR
Availability: InStock

Price 5000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Flange Motors Specification

Sealed Type
Totally Enclosed

Efficacy
High Efficiency (IE2/IE3)

Noise Level
Below 70 dB

Features
Energy Efficient, Low Maintenance, Robust Construction

Horse Power
3 HP

Rated Frequency
50 Hz

Motor Type
Flange Mounted Induction Motor

Ambient Temperature
-10C to 50C

Current Type
AC

Bearing Type
Ball Bearings

Voltage
415 V

Torque
14.6 Nm

Poles Number
4

Standard
IS:12615, IEC Standards

Power Rating
2.2 kW

Rated Voltage
415 V

Cooling Method
Air Cooled

Starting Type
Direct On Line (DOL)

Product Type
Flange Motor

Output Power
3 HP

Frequency (MHz)
Not Applicable (Frequency: 50 Hz)

Protect Feature
IP55 Protection

Phase
Three Phase

Speed
1440 RPM

Power
2.2 kW

Color
Blue/Grey

Dimension (L*W*H)
Standard Industrial Size (Approx. 320x210x260 mm)

Weight
Approx. 25 kg

Shaft Diameter
28 mm

Mounting Type
Flange Mount

IP Rating
IP55

Insulation Class
Class F

Rotor Type
Squirrel Cage

Winding Material
Copper

Applications
Industrial, Pumps, Compressors, Conveyor Systems

Vibration Level
Low (ISO Certified)

Efficiency Class
IE2/IE3

Overload Capacity
Withstand up to 150% rated load

Frame Size
112M

Duty Cycle
Continuous (S1)

Service Factor
1.15

Enclosure Type
TEFC (Totally Enclosed Fan Cooled)

About Flange Motors

Experience an unprecedented combination of performance and reliability with our distinguished Flange Motors, engineered for industrial excellence. Personalise your operations with premium features, including insulation Class F, a robust squirrel cage rotor, and energy-efficient IE2/IE3 ratings. Procure motors offering enviable IP55 protection, low ISO-certified vibration, and overload capacity up to 150% rated load. Ideal for pumps, compressors, and conveyor systems, these TEFC motors deliver continuous duty, reduced noise, and minimal maintenance-ensuring superior service life. Elevate your enterprise with unrivaled promotion of productivity.

Advantages and Features of Flange Motors

Our Flange Motors offer a distinguished advantage in industrial automation, excelling in applications such as pumps, compressors, and conveyor systems. With a robust TEFC enclosure, high efficiency ratings (IE2/IE3), and copper windings, these motors guarantee remarkable durability and consistent performance. Low vibration levels, air-cooled design, and ball bearing support make them ideal for rigorous environments. Trusted by manufacturers, suppliers, and process industries, they ensure continuous operation and enviable operational excellence with every deployment.

Payment, Supply, and Delivery Terms for Flange Motors

When you procure our Flange Motors, you benefit from flexible payment options and transparent terms. We estimate supply capacity to meet substantial industrial needs, ensuring prompt drop-off and reliable delivery timelines. Exchange and return policies cover compliance with international standards. Clients may evaluate detailed agreements prior to finalizing any exchange, while our logistics network enables efficient distribution, aiming to minimize lead time and maximize convenience for every industrial project.

FAQ's of Flange Motors:

Q: How can Flange Motors be customized for specific industrial requirements?

A: Flange Motors can be personalized with features such as insulation Class F, specific mounting types, and voltage options to suit various industrial needs, ensuring optimal compatibility and performance.

Q: What distinguishes these Flange Motors from other industrial motors?

A: These motors are distinguished by their high efficiency (IE2/IE3), Class F insulation, TEFC design, low vibration, robust construction, and overload capacity up to 150%, offering an unparalleled combination of reliability and performance.

Q: Where are Flange Motors typically used in industry?

A: Flange Motors are widely used in pumps, compressors, conveyor systems, and numerous other industrial applications where robust, reliable, and continuous operation is critical.

Q: What is the process for procuring Flange Motors?

A: The procurement process is streamlined-you can contact us for product consultation, receive tailored specifications, finalize order agreements, and schedule drop-off at your facility.

Q: What are the benefits of selecting motors with an IE2/IE3 efficiency class?

A: Selecting motors with IE2/IE3 efficiency class ensures superior energy savings, reduced operational costs, and enhanced environmental sustainability without compromising on performance.
